SAFETY

  • Overload bolt to avoid serious damage.
  • Dual switch operation required both hands tobe used for cutting cycle.
  • Two raw 08 bems infra-red curtain in front of cutting zone to avoid accident with row selection facility.

    • MACHINE DESIGN

  • Streamline box type design of parts and high grade of material
  • Box designed full length machine base for perfect load separation
  • Inbuilt hydraulic & electrical ensures safe running & low space requirement
  • Positive drive hydraulic clutch ensure quick action less wear & tear & long clutch system life
  • Almost sound less compact gear box having oil deeped warm gears fitted with tapper roller thrust bearings & high grade bushing.

    • HYDRAULIC

  • Telescopic double pressure cylinder with almost pipeless powerpack
  • Power pack inbuilt in machine base & not required & any extra motor
  • Complete hydraulic clutching device for less maintenance & seepage free operation with instant stop
  • Fully adjustable clamping pressure can be adjustable from 400kg to 3500kg as per requirement of cutting job.

    • BACK GAUGE

  • Running on precision grounded guides for speedy & precise movement * the backgauge is driven by frequency controlled ac motor with auto speed adoption for linear movement * unidirectional positioning approach to eliminate, backlash horizontal & vertical right angel setting buy knowb only
  • Calibration accuracy of ± 0.001 cms.
  • Optional / extra air table on main table & side table for easy movement of bulky stocks

    • NOTE:

    Machine Performance & Life depends on the operator skill & handling. As our Policy is to bring in continuous improvement, illustration are not binding to details. This is general Product Catalogue not a contract (Subject to Ahmadabad Jurisdiction only).

    NOTE:

    Electrical - Electronic Parts of the machine are not under guarantee or warranty. Proper electrical fittings & conditions are mandatory to avoid electrical problems.


    ELECTRICAL

  • All controls are operated buy 12 v only.
  • All operations are controlled buy single card only no use of extra hydraulic motor & electro magnetic clutch & break wich save power.

    • PROGRAMME FETURES:

    1) Programmes : cut & store lable cutting
    2) Programme storage : no programmes 99 no. of cuts in each programmes 50*
    3) Programme help : calculation function
    4) Auto selection of first blank programme*
    5) Increase & descrease of steps 30
    6) Auto cut & u-turn
    7) Computer bypass for manual cutting
    8) Remote programming flush type, dust proof, feathers.
    9) Touch keyboard for smooth operation*
    10) Symbolic key easy to understand
    11) User friendly programming features.

    STANDARD ACCESSORIES

    • Cutting line indicator
    • Hard cromed side gauge plate left & right hand
    • Knife changing kit
    • Flase clamp ( for remove of clamping impression)
    • 02 knives & 04 cutting sticks
    • Oil can, grease gun & all operational toll
    • Operational manual of machine 01 cutting line bulb 02 overload stud.

    TECHNICAL SPECIFICATIONS:

    TECHNICAL DATA

    UNIT

    72

    95

    107

    115

    CUTTING WIDTH

    MM

    720

    950

    1070

    1150

    CLAMP OPENING

    MM

    100

    130

    130

    165

    WORKING DEPTH OF TABLE (REAR)

    MM

    720

    950

    1070

    1150

    CLAMP PRESSURE MINIMUM

    Kg.

    200

    450

    450

    900

    CLAMP PRESSURE MAXIMUM

    Kg.

    1250

    3000

    3000

    4000

    RESIDUAL CUT

    MM

    20

    25

    25

    30

    BLACK GAYGE SPEED (EXPRESS)

    MM/SEC.

    200

    200

    200

    200

    TOTAL POWER

    H.P.

    5

    6

    6

    7

    WEIGHT (APPROX)

    Kg.

    2000

    3000

    3000

    4000

    NOTE: Machine Performance & Life depends on the operator skill & handling. As our Policy is to bring in continuous improvement, illustration are not binding to details. This is general Product Catalogue not a contract (Subject to Ahmadabad Jurisdiction only).

    NOTE: Electrical - Electronic Parts of the machine are not under guarantee or warranty. Proper electrical fittings & conditions are mandatory to avoid electrical problems.
