Reliable sheet separation of the air-suction bottom feeding system with automatic feeding of non-stop operation of the equipment; easy regulation of the positioning structure of the paper with accurate positioning; ensuring the precision of finished products regarding the parts of vertical and cross creasing under the high-speed running of the machine; rotary sizing applicable for any forms of glue lines; provided with the folder for the suction roller for the stable production in a high-speed state; visible and accurate regulation of the dial under the condition of fine adjustment; mounted with electric counter and automatic delivery unit on the collecting part.
TECHNICAL SPECIFICATIONS:
MODEL | LI-398 | LI-408 |
Max. size of finished envelope | 324x229mm | 380x280mm |
230x162mm | 230x162mm | |
Min. size of finished product | 85x85mm | 100x100mm |
Sheet gram | 70-150g/m | 270-150g/m2 |
Max. working speed | 10000pcs/h | 10000pcs/h |
Motor power | 2.2kw | 3kw |
Air pump power | 3kw | 5kw |
Weight of machine | :1800kg | 2600kg |
Dimension | :360x92x115cm | 480x120x130cm |
NOTE: Machine Performance & Life depends on the operator skill & handling. As our Policy is to bring in continuous improvement, illustration are not binding to details. This is general Product Catalogue not a contract (Subject to Ahmadabad Jurisdiction only).
NOTE: Electrical - Electronic Parts of the machine are not under guarantee or warranty. Proper electrical fittings & conditions are mandatory to avoid electrical problems.
